INSTRUMENT CLUSTER
5-15
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
FRONT FOG LIGHT INDICATOR
When the tail or head lights are on,
the fog lights come on if the fog light
switch is turned to the “ON” position.
Then, the fog light indicator in the in-
strument cluster comes on.
ENGINE OVERHEAT WARNING LIGHT
When the engine coolant temperate
is abnormally hot, the engine over-
heat warning light blinks and a warn-
ing buzzer sounds. When this
happens, stop the vehicle in a safe
place and let the engine cool down.
For more information, refer to Chapter 12 “When the engine
is overheating.”
If you keep driving the vehicle with the warning light and buzzer
on, the engine can be damaged. After completely cooling down the
engine have an authorized dealer or service center check the
vehicle.
CAUTION
DOOR AJAR WARNING LIGHT
This light comes on when a door or
the tailgate is either opened or not
closed completely.
This indicator illuminates when the
high beam headlamp is switched on.
HIGH BEAM INDICATOR
Driving with high beam headlamp disturbs the approaching vehicle’s
visibility. For safe driving, use the high beam headlamp only when
it is very hard to see the road.
WARNING
Driving with the door open can cause injury to people inside and
outside the vehicle.
• Before driving off, close all doors.
• Check whether or not the light is off.
WARNING
