SERVICE AND MAINTENANCE
13-14
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
POWER STEERING FLUID
Check the fluid level on a level ground with the engine turned
off. The fluid level should be between the MIN and MAX marks
on the reservoir cap gauge. If it drops to or below the MIN
mark, refill the reservoir with the specified fluid. Only use
the specified fluid. The difference between the MIN and MAX
marks shows fluctuations of the steering fluid between when
it is hot and when it is cold.
Specification and Capacity
Power steering
fluid reservoir
Diesel Engine
Gasoline Engine
Power steering
fluid reservoir
Max
Max
Min
Min B zone
A zone
NOTE 1: The underhood fuse and relay box has some spare fuses.
Refill the fuses immediately as you use them. The fuse rating is
indicated on the upper surface of the fuse.Super multigrade fluid
with an exceptionally high viscosity index and a very low pour point,
allowing functionality of hydraulic systems at extremely low
temperatures. Excellent lubricating properties even at very low and
very high temperatures.
ATF DEXRON II or III
Approx. 1.0
See NOTE 1: TOTAL FLUIDE DA
(Extreme cold condition only)
Specification
Capacity (L)
