INSTRUMENT CLUSTER
5-14
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
4WD INDICATORS (PART TIME T/C ONLY)
4WD Low Indicator*
When shifting the driving mode to
“4L”, this indicator blinks until the
shifting operation is completed. After
completion of the mode change to 4L,
the indicator comes on.
4WD Check Warning Light*
This warning light comes on when
the ignition switch is turned to “ON”
and should go out if the system is
normal. If the “4WD CHECK” warning
light stays on, have the 4WD system
checked by a Ssangyong Dealer or
Ssangyong Authorized Service Center.
4WD High Indicator*
When shifting the driving mode from
“4L” to “4H”, this indicator blinks until
the shifting operation is completed. Af-
ter completion of the mode change to
4H, the indicator comes on. Shift the
driving mode from 2WD to 4WD HIGH
only when the vehicle speed is under 70 km/h.
When shifting the driving mode from 4WD LOW to 4WD HIGH, this
indicator will blink until the shift is completed. After completion of
the shifting operation, the indicator stays on. The indicator comes
on without blinking when shifting from 2WD to 4WD HIGH.
NOTE
• If the “4WD CHECK” warning light stays on, have the 4WD sys-
tem checked.
• Do not drive your vehicle over 80 km/h in 4H mode.
CAUTION
