INSTRUMENT CLUSTER
5-2
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
40
60
80
20
km/h
0
220
200
HF
CE
x1000rpm
0
2
6
5
4
3
INSTRUMENT CLUSTER
1. Tachometer
2. Speedometer
3. Left turn signal indicator
4. Right turn signal indicator
5. Engine coolant temperature gauge
6. Fuel gauge
7. Engine overheat warning light
8. Fog light indicator
9. High beam indicator
10. Door ajar warning light
11. Seat belt reminder (passenger’s seat)
12. Brake warning light
13. Low fuel level warning light
14. Winter mode indicator
15. ESP warning light
16. 4WD HIGH indicator
17. Battery charge warning light
18. Air bag warning light
19. HDC indicator
20. Immobilizer indicator
21. Water separator warning light
22. Seat belt reminder (driver’s seat)
23. 4WD LOW indicator
24. 4WD CHECK warning light
25. Auto shift indicator (for automatic
transmission)
26. ODOmeter/ Trip odometer
27. ABS warning light
28. EBD warning light
29. Engine hood open warning light
30. Glow indicator
31. Engine check warning light
32. Engine oil pressure warning light
33. Auto cruise indicator
34. SSPS warning light
35. Hazard warning light (Eastern
Europe only)
D20DT, D27DT
