VENTILATION, HEATING, AIR CONDITIONING AND AIR PURIFICATION SYSTEM
9-15
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
REPLACING AIR CONDITIONER FILTER
2. Remove the glove box from the dash
panel by moving the left side of the
holder in the direction of the arrow.
3. Push down the right side of the glove
box in the direction of the arrow.
1. Open the glove box.
Replace the air conditioner filter when
• Unpleasant odor is generated at the first operation after a long unused period.
• Cooling and blowing capacity have decreased.
• Do not apply excessive force to the holders when removing
the glove box. It may cause a deformation of holders and re-
sults in a loose installation.
• Replace both air conditioner filters at the same time while pay-
ing attention to the installing direction.
CAUTION
• Replace the air conditioner filter at every 10,000 km of driving.
However, if the vehicle is operated under severe conditions,
such as on dusty or unpaved roads, and excessive air condi-
tioner or heater use, the replacement interval can be shortened.
• When the filter is contaminated, it will decrease the cooling or
heating capacity of the system and creates unpleasant odors.
CAUTION
