SERVICE AND MAINTENANCE
13-3
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Coolant surge tank
Engine oil dipstick
Brake and clutch fluid reservoir
(for manual transmission)
Front washer
fluid reservoir
Relay and fuse box
Power steering
fluid reservoir
Engine oil filler cap
Air cleaner
Battery
1
Without Additional
Water Separator
3
1
3
2
1. Priming pump 2. Water separator 3. Fuel filter
LOCATIONS IN ENGINE COMPARTMENT
D27DT DIESEL ENGINE
Do not work on the engine compartment while the engine, radiator, exhaust manifold, muffler
or catalytic converter is hot. Always turn the engine off and allow it to cool before starting
the maintenance.
CAUTION
With Additional
Water Separator
