SERVICE AND MAINTENANCE
13-13
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
AIR CLEANER
Cleaning
Air cleaner
Diesel Engine
Gasoline Engine
Air cleaner
• If you blow the compressed air to the opposite direction, the engine will be damaged due
to foreign materials entering.
• Be careful with the direction of the compressed air on the air cleaner.
CAUTION
• Do not drive your vehicle with an improperly installed air cleaner element or without it. It
may damage the engine or may cause a fire.
• Do not let any object enter the housing when cleaning the air cleaner. It may damage the
engine or may cause an engine to stall.
WARNING
Diesel
Gasoline
EU: Initial clean: 5,000 km, clean every
15,000 km, replace every 30,000 km
(But, shorten the service interval under
severe condition)
GENERAL: Initial clean: 5,000 km, clean
every 10,000 km, replace every 30,000 km
(But, shorten the service interval under
severe conditions)
Clean every 15,000 km, replace every
60,000 km (But, shorten the service
interval under severe conditions)
Change
1. Unscrew the cover bolts and remove the cover.
2. Replace the air cleaner element with a new one. Make
sure that the element is correctly installed in the air
cleaner housing.
3. Close the cover and tighten the bolts.
If vehicle is operated under severe condition
• Pollutant area or off-road driving
• Driving in dusty condition or sandy condition
frequently inspect the air cleaner, if necessary, change the air cleaner.
CAUTION
Blow the compressed air through the element in the
opposite direction to normal air flow to clean the
element.
