LAMP
14-9
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
TAILGATE COMBINATION LAMP
1. Remove the ignition key from the
key cylinder.
2. Open the tailgate.
3. Remove the bolt cover on the tail-
gate and remove the three bolts.
4. Remove the rear combination lamp
housing while pushing it rearward.
5. Turn the bulb housing to remove it.
6. Remove the bulb while pushing
and turning it.
7. Remove the back-up lamp bulb.
8. Replace it with a new one.
9. Install in the reverse order of
removal.
Tailgate combination lamp
Tail lamp
Rear fog
lamp
Back-up
lamp
