VENTILATION, HEATING, AIR CONDITIONING AND AIR PURIFICATION SYSTEM
9-13
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Mode Switch
By pressing these switches, the air flow mode changes. When each mode is selected, its indicator will come on.
Defroster Switch
Use this switch for quick defrosting.
When you press this switch, the airflow direction will be
changed to the windshield and door glasses, the air condi-
tioner operates automatically, outside air comes in, and the
indicator on the switch comes on. When the switch is
pressed again, the previous mode will be restored.
When the defrosting is completed, press the switch to re-
turn to normal operations.
Defroster indicator
Vent Bi-level Floor Defroster and Floor
