7 - Debugger and PROM Programmer Tutorial for ST72251
7.1.2 Starter Kits
TheStarterKitsareexistinthreeflavors,eachprovidingadifferentEPROMprogramming
board. They include the STMicroelectronics Software Tools, so that the board can be driven
using the EPROMER software. They do not provide any emulating capability but the De-
bugger can run in simulation mode. They also include a selection of ST7 chips depending on
the flavor selected.
They exist as the following models:
ST7MDT1-KIT for the ST72101, ST72212, ST72213 and ST72251 except R and N variants;
ST7MDT2-KIT for the ST72121, ST72311 and ST72331 except N6 variants;
ST7MDT4-KIT for the ST72272 and ST72671.
7.1.3 Development Kits
The Development Kits go a step further than the Starter Kits, for the board supplied is at the
same time an EPROM Programmer and a low-cost emulator. Roughly speaking, they provide
all that emulators do, except real-time tracing. They constitute a very convenient and cost-ef-
fective development tool. They also include a selection of ST7 chips plus the software tools
and documentation. They exist in the following models:
ST7MDT1-DVP for the ST72101, ST72212, ST72213 and ST72251 except R and N
variants;
ST7MDT2-DVP for the ST72121, ST72311 and ST72331 except N6 variants.
7.1.4 Emulators
The Emulators provide the full functionality of debugging and real-time tracing for all the mem-
bers of the ST7 family. They come with the Debugger software.
They exist in the following models:
ST7MDT1-EMU for the ST72101, ST72212, ST72213 and ST72251 except R and N
variants;
ST7MDT2-EMU for the ST72121, ST72311 and ST72331 except N6 variants;
ST7MDT3-EMU for the ST72311N6, ST72331N6 and ST72251N and R variants.
ST7MDT4-EMU for the ST72272 and ST72671.
7.2 EPROM PROGRAMMER BOARDS
In this section we describe the installation and use of the EPROMER software and the
EPROM Programming Boards, or the EPROM programming part of the Development Boards.
All these boards are supplied with:
