Item Q.ty Ref. Value Description Manufacturer Order code
37 1 P1 Header 4 Luxshare LD81FP008-1H
38 1 P3 Header 4X2 Harwin M20-9980445
39 1 P6 Header 8 Harwin M20-9730845
40 1 R1 6k8 SMD 0603 RES Panasonic ERJ-3GEYJ682V
41 1 R2 220k SMD 0603 RES Panasonic ERJ-3GEYJ224V
42 1 R6 N.M. SMD 0805 RES N.M. N.M.
43 1 R16 150k SMD 0603 RES Panasonic ERJ-3GEYJ154V
44 1 R21 820 SMD 0603 RES Panasonic ERJ-3GEYJ821V
45 1 R22 47k SMD 0603 RES Panasonic ERJ-U03J473V
46 1 R26 1M SMD 0603 RES Panasonic ERJ-3GEYJ105V
47 1 R32 4k7 SMD 0603 RES Panasonic ERJ-3EKF4701V
48 2 R33, R29 N.M. SMD 0603 RES N.M. N.M.
49 1 R34 5k1 SMD 0603 RES Panasonic ERJ-3GEYJ512V
50 1 S1 SW-SPST Bright P-DT2112C
51 1 U1 STWLC38 STMicroelectronics STWLC38JRM
52 1 U2 FT260Q FTDI FT260Q
53 1 U4 SOT23-6 STMicroelectronics USBLC6-2SC6
54 1 COIL Luxshare LD81FP008-1H
55 4 Standoff Harwin R30-6700394
56 4 Screw Wurth 97790803111
57 1
Pair of wires between COIL and
PCB
CNC Tech 610224
58 1 Glue Loctite LOCTITE 454
59 3 2.54 jumper Wurth 60900213421
UM3154
Bill of material (BOM)
UM3154 - Rev 2
page 42/81
