www.stryker.com 1115 -10 9 - 0 01 R E V D 25

Return To Table of Contents

ADJUSTING TRENDELENBURG/REVERSE TRENDELENBURG POSITIONS - SIDE CONTROL

HYDRAULICS

Litter height must first be raised in order to achieve a Trendelenburg or reverse Trendelenburg position.

CAUTION

• To avoid damage, remove any equipment that may be in the way before raising or lowering the litter height.

• Do not raise the unit (hydraulics on base) with a patient lift under the stretcher.

For Trendelenburg positioning (head down), depress the side of pedal (B) closest to the head end (see Figure 7 on

page 22).

For reverse Trendelenburg positioning (foot down), depress the side of pedal (B) closest to the foot end (see Figure

7 on page 22).

To lower the stretcher from reverse Trendelenburg position, depress pedal (A) once to raise the foot end of the

stretcher, and then depress pedal (B) (see Figure 7 on page 22).

Note: The higher the litter is before pedal (B) is activated, the greater the Trendelenburg or reverse Trendelenburg

angle will be. (Maximum Trendelenburg angle is +17°. Maximum reverse Trendelenburg angle is -17°.)

ADJUSTING TRENDELENBURG/REVERSE TRENDELENBURG POSITIONS - OPTIONAL THREE-SIDED

OR FOUR-SIDED CONTROL HYDRAULICS

Litter height must first be raised in order to achieve a Trendelenburg or reverse Trendelenburg position.

CAUTION

• To avoid damage, remove any equipment that may be in the way before raising or lowering the litter height.

• Do not raise the unit (hydraulics on base) with a patient lift under the stretcher.

For Trendelenburg positioning (head down) (see Figure 8 on page 23):

• Depress pedal (D) at the foot end of the unit or

• Depress the side of pedal (C), located on the patient left or patient right side, closest to the head end of the unit.

For reverse Trendelenburg positioning (foot down) (see Figure 8 on page 23):

• Depress pedal (B) at the foot end of the unit or

• Depress the side of pedal (C), located on the patient left or patient right side, closest to the foot end of the unit.

To lower the stretcher from reverse Trendelenburg position, depress pedal (A) once to raise the foot end of the

stretcher, and then depress pedal (C) or (D) (see Figure 8 on page 23).

Note: The higher the litter is before pedal (B), (C), or (D) is activated, the greater the Trendelenburg or reverse

Trendelenburg angle will be. (Maximum Trendelenburg angle is +17°. Maximum reverse Trendelenburg angle is -17°.)
