Operation Guide
OPERATING THE REMOVABLE I.V. POLE
To use the removable I.V. pole:
1. Remove the I.V. pole from the storage trough under the litter and insert into
the receptacle on the corner of the litter frame.
2. To raise the height of the pole, turn the knob (B) counterclockwise and pull
up on the telescoping portion (A) of the pole to raise it to the desired height.
3. Turn the knob (B) clockwise to lock the telescoping portion in place.
CAUTION
• To avoid damage to the removable I.V. pole, the weight of the I.V. bags should
not exceed 40 lb.
• To avoid damage while transporting the stretcher, verify that the I.V. pole is
at a low enough height to allow it to safely pass through door openings and
under light fixtures.
• Do not use the I.V. pole as a push/pull device because equipment damage
could occur.
INSTALLING THE SIDERAIL PADS
To install and use the siderail pads, tuck the siderail pad between the mattress
and siderail. Then, attach the Velcro® straps around the top of the siderail to
secure the pad to the siderail.
Figure 47: Removable I.V. Pole
A
B
