This manual is designed to assist you with the operation of Stryker Model 1115 Prime Series Stretcher. Read this
manual thoroughly before using the equipment or beginning maintenance on it. To ensure safe operation of this
equipment, it is recommended that methods and procedures be established for educating and training staff on the safe
operation of this stretcher.
PRODUCT DESCRIPTION
The Stryker Model 1115 Prime Series Stretcher with Big Wheel® decreases start-up force by 50 percent and steering
effort by 60 percent.
INTENDED USE OF PRODUCT
The Stryker Model 1115 Prime Series Stretcher is a wheeled device which consists of a platform mounted on a wheeled
frame that is designed to support patients in a horizontal position. The device has siderails and has the option available
to support the temporary or permanent placement of I.V. poles. A stretcher provides the caregiver a method of
transporting patients within a healthcare facility. The device has a two Big Wheels which reduces the required start-up
force to move the stretcher. Some stretchers may also be used for minor procedures and short-term stay (treatment
and recovery).
INTENDED USE OF PRODUCT - PRIME X OPTION
The Prime X option provides a platform for the short-term outpatient clinical evaluation and treatment of human patients
and additionally may be used for minor procedures and short-term outpatient stay (treatment and recovery). The Prime
X option provides an articulating radiographic patient support surface and a platform below the patient support surface
for X-Ray cassette placement to allow the capture of clinical X-Rays (AP Full Body, optional Full Body Lateral, and
optional Upright Chest) when used in conjunction with a medical X-Ray system. The Prime X option is a wheeled device
consisting of a platform mounted on a wheeled frame that is designed to transport patients in a horizontal position
within the interior of a healthcare facility by health professionals and/or trained representatives of the user facility. The
device has siderails and optional supports for fluid infusion equipment.
The Prime X option is intended to be used to transport patients to and from all departments within the interior of a
healthcare facility. The use of the Prime X option as a short-term outpatient clinical evaluation, treatment, minor
procedure, and short-term outpatient recovery platform may include use in, but not limited to, the Emergency Department
(ED), including the Trauma area, and Post-Anesthesia Care Unit (PACU). The Prime X option is not intended to be used
for long-term inpatient treatment and recovery. See the specification table in the operations manual of the device for
the intended environmental conditions.
The Prime X option has a safe working load up to 700 pounds (318 kg) and is intended to be used with all patients,
including those mildly to critically ill. The stretcher may also be used to transport deceased patients within an enclosed
healthcare facility.
The Prime X option has an optional scale system intended to measure and display weight in pounds or kilograms of
patients weighing 50 to 700 pounds (22.7 to 318 kg) and patients not exceeding the height of 75.25 inches (191 cm).
See the specification table for accuracy claims.
The Prime X option has an expected life of 10 years under normal use, conditions, and with appropriate periodic
maintenance as described in the maintenance manual for each device.
The Prime X option is not recommended for use with a Stryker Pioneer mattress or a mattress with a thickness
greater than four inches and is not compatible for use with a C-Arm. The Prime X option is intended for use in all
establishments other than home healthcare, domestic, and those directly connected to the public low voltage power
supply network that supplies buildings used for domestic purposes.
Introduction
