REPLACING THE OPTIONAL SCALE SYSTEM BATTERIES - NON-ELECTRIC LITTER
To avoid completely draining the batteries and having the optional scale system shut down, replace the batteries
whenever only one of the charge indicator bars on the display (1) is black as shown on page 40.
To replace the scale system batteries:
1. Remove the Phillips head screws that hold the battery compartment cover to the display assembly.
2. Replace all four AA batteries.
• Install the positive and negative poles as indicated on the battery holder.
• Use only Alkaline type (LR6) batteries.
• Do not mix old and new batteries.
• Properly dispose of the old batteries in accordance with local regulations.
3. Reinstall the screws and the cover.
If the display is flashing “Lo batt”, then the batteries are drained and the scale system is disabled. Replace the batteries
with four new AA batteries as described above.
