OPERATING THE GATCH - OPTIONAL ELECTRIC LITTER (NOT AVAILABLE WITH PRIME X OPTION)
Ensure that the power cord is plugged into a properly grounded, hospital grade wall outlet before using the optional
electric litter.
To raise the gatch, press the UP (2) button on the siderail patient controls (A) or foot end nursing controls (B) until the
gatch has reached the desired height (5.5”/14 cm minimum) as shown in Figure 26.
To lower the gatch, press the DOWN (1) button until the gatch has reached the desired height (5.5”/14 cm minimum)
as shown in Figure 26.
WARNING
Use caution when operating the gatch while a patient is on the stretcher. Powered stretcher mechanisms can cause
serious injury. Operate stretcher only with persons clear of mechanisms.
Operation Guide
Figure 26: Gatch - Electric Option
3 4
21
123 4
B
A
CAUTION
The weight capacity of the gatch is 200 lb. Do not sit or stand on the gatch. Injury or damage to the equipment could
occur.
