Operation Guide
USING THE OPTIONAL RETRACTABLE CORD REEL - ELECTRIC LIFT/LITTER OPTION
The retractable cord reel (A) stores the stretcher power cord during transport as shown in Figure 30.
To use the retractable cord reel:
1. Pull the cord out of the reel to the desired length.
2. Plug the power cord into a properly grounded, hospital
grade wall outlet.
To store the power cord:
1. Unplug the plug by grasping the mold near the outlet and
pull the cord in a direction parallel to the floor (not at an
angle).
2. Tug and release the cord to retract the cord back into the
cord reel.
WARNING
If your unit is equipped with the optional electric lift/litter, unplug
the power cord from the power outlet before transporting or
cleaning the unit. To unplug, grasp the mold near the outlet and
pull the cord in a direction parallel to the floor (not at an angle).
Figure 30: Optional Retractable Cord Reel
A
