Operation Guide
USING X-RAY CASSETTES - PRIME X OPTION
The Prime X option provides an articulating radiographic patient support surface and a platform below the patient
support surface for X-Ray cassette placement to allow the capture of clinical X-Rays (AP Full Body, optional Full Body
Lateral, and optional Upright Chest) when used in conjunction with medical X-Ray systems.
WARNING
When using the Prime X option in conjunction with devices that generate X-radiation, the generating devices may
produce residual, stray, and/or scattered radiation. Users should refer to local, state, and federal use guidelines as
well as appropriate facility protocols for safety before use. Special attention should be given when performing X-Rays
with the stretcher’s fowler in the upright position and also when performing X-Rays using a lateral cassette.
You can insert and remove cassettes from the head end,
foot end and both sides of the stretcher as shown in
Figure 35.
Center the patient on the stretcher by using the position
indicator labels that are located on all sides of the stretcher.
WARNING
The Prime X option is not recommended for use with a
Stryker Pioneer mattress or a mattress with a thickness
greater than four inches and is not compatible for use with
a C-Arm.
Figure 35: Cassette Locations
