www.stryker.com 1115 -10 9 - 0 01 R E V D 35
Return To Table of Contents
OPERATING THE RECOVERY CHAIR (NOT AVAILABLE WITH PRIME X OPTION)
CAUTION
To achieve recovery chair position, your stretcher must be equipped with the lift assist backrest and gatch options.
To place the stretcher into the recovery chair position as shown in Figure 27:
1. Raise the fowler to a seated position (for manual operation, see page 31; for the optional electric litter operation,
see page 32).
2. Fully raise the gatch (for manual operation, see page 33; for the optional electric litter operation, see page
34).
3. Raise the stretcher to its highest height (for side control, see page 22; for three-sided or four-sided controls, see
page 23; for optional electric litter operation, see page 24).
4. Place the stretcher into the full reverse Trendelenburg position (see page 25).
To lower the stretcher from the recovery chair position:
1. Raise the stretcher to its highest height (for side control, see page 22; for three-sided or four-sided controls, see
page 23; for optional electric litter operation, see page 24).
2. Lower the fowler from the seated position (for manual operation, see page 31; for the optional electric litter
operation, see page 32).
3. Lower the gatch (for manual operation, see page 33; for the optional electric litter operation, see page 34).
WARNING
Use caution when operating the recovery chair while a patient is on the stretcher. Powered stretcher mechanisms can
cause serious injury. Operate stretcher only with persons clear of mechanisms.
Operation Guide
Figure 27: Recovery Chair
