www.stryker.com 1115 -10 9 - 0 01 R E V D 9
Return To Table of Contents
IntroductionIntroduction
SPECIFICATIONS
26” Width 30” Width Option
Prime X Option
30” Width
Safe Working Load
Note: Safe Working
Load indicates the sum
of the patient, mattress,
and accessory weight.
700 lb 318 kg 700 lb 318 kg 700 lb 318 kg
Overall Stretcher Length 85” (± .5”) 215.9 cm 85” (± .5”) 215.9 cm 85” (± .5”) 215.9 cm
Overall Stretcher Width
(Siderails Up)
34” (± 1”) 86.4 cm 38” (± 1”) 96.5 cm 38” (± 1”) 96.5 cm
Overall Stretcher Width
(Siderails Down)
30.25”
.5)
76.8 cm
30.5”
.5)
77.5 cm
30.5”
.5)
77.5 cm
Minimum/Maximum
Stretcher Height
20.75” /
34” (± 1”)
52.7 cm /
86.4 cm
20.75” /
34” (± 1”)
52.7 cm /
86.4 cm
23.25” /
36.5” (± 1”)
59.1 cm /
92.7 cm
Fowler Angle 0° to 90° (± 5°)
Gatch Height 5.5” (14 cm) minimum Not applicable
Trendelenburg/Reverse
Trendelenburg
+17°/-17° 3°)
Minimum Under-
Stretcher Clearance
2.5”
nominal
6.4 cm
2.5”
nominal
6.4 cm
2.5”
nominal
6.4 cm
1.75
under the
hydraulic
jacks and
fifth wheel
4.5 cm
1.75
under the
hydraulic
jacks and
fifth wheel
4.5 cm
1.75
under the
hydraulic
jacks and
fifth wheel
4.5 cm
1” under
the Big
Wheel
2.5 cm
1” under
the Big
Wheel
2.5 cm
1” under
the Big
Wheel
2.5 cm
Attenuation Equivalent
(Aluminum Equivalence)
Not applicable
Maximum Value
Allowed is 1.7 mm Al
