24 1115 -10 9 - 0 01 R EV D www.stryker.com
Return To Table of Contents
Operation Guide
RAISING AND LOWERING THE LITTER HEIGHT - OPTIONAL ELECTRIC LIFT
Ensure that the power cord is plugged into a properly grounded, hospital grade wall outlet before using the optional
electric lift.
CAUTION
To avoid damage, remove any equipment that may be in the way before raising or lowering the litter height.
To raise the litter height electrically, depress pedal (A) (see Figure 7 on page 22 or Figure 9 on page 23). The
litter will begin to raise. Hold the pedal down until the desired litter height is achieved. Release the pedal at any time
to stop the litter motion.
To lower the litter height manually, see the “Operating the Base Controls - Side Control Hydraulics” information on
page 22 or “Operating the Base Controls - Optional Three-Sided or Four-Sided Hydraulic Controls information” on
page 23. The litter height does not lower electrically.
WARNING
• Patients should be discouraged from sitting directly on the ends of the stretcher. Excessive weight could cause
the litter surface to tip up, possibly causing patient injury.
• Leave the stretcher height in the lowest position when the patient is left unattended. Leaving the stretcher height in
a raised position could increase the chance of patient falls and injury.
To Next Page
