OPERATING THE FOOT END NURSING CONTROLS - OPTIONAL ELECTRIC LITTER (NOT AVAILABLE
WITH PRIME X OPTION)
Ensure that the power cord is plugged into a properly grounded, hospital grade wall outlet before using the optional
electric litter.
The foot end nursing controls allow the operator to position the fowler and gatch as shown in Figure 16. The power
cord must be plugged into the wall socket for the nursing controls to operate.
WARNING
Powered stretcher mechanisms can cause serious injury. Operate stretcher only with persons clear of mechanisms.
Button Button Name Button Function
1 Gatch Down Press to lower the gatch (foot section)
2 Gatch Up Press to raise the gatch (foot section)
3 Fowler Up Press to raise the fowler (head section)
4 Fowler Down Press to lower the fowler (head section)
Operation Guide
Figure 16: Foot End Nursing Controls - Optional Electric Litter
123 4
