pg 7
Mono In - Mono Out: To connect Brig in a mono signal chain, use TS
cables for both Brig’s IN and OUT� Set the I/O Selector switch to mono�
Mono In - Stereo Out: To feed a mono signal into Brig, use a TS cable to
Brig’s IN� Connect a TRS + dual TS cable to Brig’s OUT to route Brig’s
stereo signal to a stereo pedal� Set the I/O Selector switch to mono
stereo�
Stereo In - Stereo Out: To connect Brig in a stereo signal chain, use TRS
+ dual TS cables into both Brig’s IN and OUT� Set the I/O Selector switch
to stereo�
*NOTE: Alternatively, you can use a TRS - TRS cable when connecting a pedal
with a TRS stereo input or output (such as connecting to the TRS stereo input of
a Strymon cloudburst stereo reverb)�
