pg 8
Rear Panel I/O and Control (continued)
9VDC
Only use an adapter with the
following rating:
• 2�1mm, center-negative
• 9VDC
• 250mA minimum
(Adapter sold separately�)
USBC
Computer connection for MIDI
I/O and firmware updates�
EXP/MIDI
Multifunction communication jack for external control of Brig’s features
and functions� Can be set to operate in one of the following modes� (See
“Configuring the EXP/MIDI Jack” on page 13 for details�)
Expression Pedal Mode (see page 16)�
Favorite Mode (see page 17)�
Tap Mode (see page 19)�
Infinite Mode (see page 19)�
MIDI Mode (see “Configuring Brig for MultiSwitch Plus” on page 22
or “Saving Presets in MIDI Mode” on page 31)�
