1656 & 1657 Battery Element Tester Owner’s Manual
STS Instruments Page 36 of 88
TEST SETUP <n> MENU
Entry Type Description
TEST TIME
INTERVAL
Parameter This setting determines the time between repeated
applications of the test voltage to the unit under test.
Minimum test interval programmable is a function of the
1656/1657 hardware revision and test voltage set per
the table below.
Hardware revisions AB and lower:
Test Voltage Range Min. Test Time Interval
300 V – 1790 V 30 msec
1800 V – 2190 V 65 msec
2200 V – 3000 V 500 msec
Hardware revisions AC or higher:
Test Voltage Range Min. Test Time Interval
300 V – 2490 V 30 msec
2500 V – 3000 V 65 msec
Maximum test interval is 5000 msec for all revisions.
