STS 1656 - Status Reporting

1656 & 1657 Battery Element Tester Owner’s Manual
STS Instruments Page 66 of 88
BIT NAME WEIGHT DEFINITION
3
DDE
8
DEVICE DEPENDANT ERROR indicates instrument
not properly configured
2
QYE
4
QUERY ERROR indicates cannot respond with data
1
RQC
2
REQUEST CONTROL - not used
0
OPC
1
OPERATION COMPLETE indicates previous
operation complete
Setting an EVENT STATUS ENABLE (ESE) bit true unmasks the EVENT bit in the ESR. Also see
:SYSTem:ERRor? query for corresponding information.
8.6.3 Status Reporting
The following lists the SCPI Commands for Status Reporting from the instrument. Refer to the
SCPI 1999 standard for more information. Query commands are explicitly shown in this section
for clarity.
SYSTem:ERRor? Query: system error
Returns one of the following types of messages, with details appended to it if possible. A
maximum of 256 characters may be sent as a response to this query. Negative error messages
(< 0) are defined in the SCPI Standard. Positive error message (> 0) are instrument specific.
The table below indicates the error query responses that are be supported.
Error Message Description
100, "Test Failed"
Test performed returned FAIL result
If the number of measurements taken is 5 (MEAS:VOLT:AC? 5)
and reading #1 fails while readings 2, 3, 4 and 5 pass, the
tester will still report a FAIL result. This test failed flag is
latched until the message is read at which time it is cleared.
For the Auto-Line option, when performing a measurement
(MEAS:VOLT:AC? 1) and cell #1 and #3 happen to fail, the
message queue will contain a 100 error message for each cell
number that failed.
100, "Test Failed
n,n,n,n,n,n"
Test performed in Auto Line mode returned at least one FAIL
result
For the Auto-Line option, when performing a measurement
(MEAS:VOLT:AC? 1) and cell #1 and #3 happen to fail, the error
message will contain PASS or FAIL indications for each cell.
Example: 100, “Test Failed FAIL, PASS, FAIL, PASS, PASS, PASS
0, "No error" No error detected
-102, "Command error" Indicates invalid command or query received
-200, "Execution error" Indicates can't execute command with parameters received
-300, "Device-specific error" Indicates instrument not properly configured
-350, "Query overflow"
A specific code entered into the queue in lieu of the code that
