1656 & 1657 Battery Element Tester Owner’s Manual
STS Instruments Page 51 of 88
8.3 SCPI Commands Summary
Following table lists all available programming commands. Details for each command follow in
subsequent paragraphs.
Command Type Notes
CALIBRATION Commands
CALibration:MEASure:VOLTage:LOW<space><n>
Command
n = 1 - 900
CALibration:MEASure:VOLTage:LOW?
Query
CALibration:MEASure:VOLTage:MEDium<space><n>
Command
n = 1 - 900
CALibration:MEASure:VOLTage: MEDium?
Query
CALibration:MEASure:VOLTage:HIGH<space><n>
Command
n = 1 - 900
CALibration:MEASure:VOLTage: HIGH?
Query
MEASURE Commands
MEASure:VOLTage:AC? <space><n>
Query
Returns n Q readings
MEASure:VOLTage:PEAK? <space><n>
Query
Returns n peak voltage
readings
OUTPUT Commands
OUTPut < 0 | 1 >
Command
OUTPut?
Query
OUTPut:COUNt <space><n>
Command
n = 0 ~ 999 (0 = continuous)
OUTPut:COUNt?
Query
OUTPut:TINTerval <space><n>
Command
n = 30 ~ 5000 (msec)
OUTPut:TINTerval?
Query
SOURCE Commands
[SOURce:]VOLTage[:LEVel][:IMMediate][:AMPLitude] <n>
Command
[SOURce:]VOLTage[:LEVel][:IMMediate][:AMPLitude]?
Query
[SOURce:]VOLTage[:LEVel]:TRIGgered <min>, <max>
Command
[SOURce:]VOLTage[:LEVel]:TRIGgered?
Query
STATUS Commands
STATus:OPERation:CONDition?
Query
STATus:QUEStionable:CONDition?
Query
STATus:OPERation:ENABle<space> <n>
Command
STATus:OPERation:ENABle?
Command
STATus:QUEStionable:ENABle <space><n>
Command
STATus:QUEStionable:ENABle?
Query
STATus:OPERation:EVENt?
Query
STATus:QUEStionable:EVENt?
Query
SYSTEM Commands
SYSTem:CALibration:DATE?
Query
SYSTem:VERSion?
Query
SYSTem:SERialnumber?
Query
SYSTem:ERRor?
Query
SYSTem:DATE <space><yyyy>, <mm>, <dd>
Command
SYSTem:DATE?
Query
SYSTem:TIME <space><hh>, <mm>, <ss>
Command
24 hour format
SYSTem:TIME?
Query
24 hour format
SYSTem:BEEPer:MODE <space><off | high>
Command
Table 8-1: STS 1656 & 1657 SCPI Command Summary Table
