5 TECHNICAL SPECIFICATIONS
Mic / Line Inputs Conditions / Details Value
General Conditions: Gain setting 15 dBu
0 dB
FS
unless otherwise noted
Input Level Range
Max. level @ 0dB
FS
, 86 one-dB steps –60 to +26 dBu
Input Impedance
6.8 kΩ
Frequency Response
+0 dB / –0.3 dB 20 Hz to 20 kHz
+0 dB / –0.2 dB 30 Hz to 20 kHz
THD+ Noise
1 kHz, –1 dB
FS,
15 dBu < –97 dB
20 Hz to 20 kHz, –30 dB
FS
< –110 dB
Common Mode Rejection Ratio (CMRR)
30 Hz to 20 kHz, full gain range > 70 dB
1 kHz, < -20 dBu, > 35 dB gain 100 dB typ.
Crosstalk
1 kHz ≤ –110 dB
Equivalent Input Noise
R
source
= 200 Ω, maximum gain –126 dBu
RF Rejection
RF rejection with common mode choke Yes
Analogue High-Pass Filter
switchable 75 Hz, 12 dB/Oct
Phantom Power
switchable 48 V
Zero cross detection and Sample & Hold
for click free gain changes Yes
Line Inputs Conditions / Details Value
Max. Input Level
Max. level @ 0 dB
FS,
four steps, software controlled +9, +15, +18, +24 dBu
Input Impedance
> 10 kΩ
Frequency Response
20 Hz to 20 kHz +0 dB / –0.2 dB
THD + Noise
1 kHz, –1 dB
FS,
15 dBu < –97 dB
20 Hz to 20 kHz, –30 dB
FS
< –110dB
Common Mode Rejection Ratio (CMRR)
30 Hz to 20 kHz, all four gain settings > 60 dB
Crosstalk
1 kHz > –110 dB
RF Rejection
Yes
Line Outputs Conditions / Details Value
Max. Output Level
Max. level @ 0 dB
FS,
four steps, software controlled +9, +15, +18, +24 dBu
Output Impedance
40 Ω
Electronically balanced
Yes
AES/EBU Inputs Conditions / Details Value
Input Sensitivity
0.2 V
Input Impedance
110 Ω
SRC Range
32 to 192 kHz
Latency Conditions / Details Value
Input to Output Delay
Mic In - ADC - DSP - DAC - Line Output 1.8 ms
AES/EBU Outputs Conditions / Details Value
Output Level
3 V
Output Impedance
110 Ω
Power Supply Conditions / Details Value
Primary Input Voltage Range
Power supply auto-ranging, with power factor correction (PFC);
EN/UL approved
100 to 240 V AC ± 10%
50 to 60 Hz
Power Consumption
Micro Core 100 W
Weights Value
Micro Core
7 kg
