Micro Series
Micro Series 1-19
Document generated:29.06.17
SW V1.1
2.1.4 Send View
The send view shows the mixers four send channels. Each of these four chan-
nels can either be an Aux or N-1 send. Here, the send master faders can be
operated.
[1]
[2]
[5]
[6]
[7]
[8]
[1] Label The label display shows the send channels name. This name can be entered
in the Options page of the send channel.
[2] Talk button This button can be used to talk to the output of this send channel.
[5] SIG Indicator The green signal indicator is illuminated as soon as the signal on the send bus
is > -40dB. The signal is captured before the send fader.
[6] Fader The send fader. It can be operated by mouse or touch. The mousewheel can
also be used to operate the fader when hovering the mousepointer anywhere
over the fader area.
[7] On button The On button activates the send channel.
[8] PFL button The PFL button allows the operator to pre- listen to this channel even if the
fader is closed or the channel is not switched to ‚On‘. PFL stands for PreF-
adeListening. The Reset PFL button in the central section releases all channels
from PFL.
