2.1.2 Mixer Channels
Before the channel view is explained, it is essential to understand the concept
of having different channel roles.
2.1.2.1 Channel Roles
All twelve DSP channels are identical. But every channel can be given a
specific “role”. The role links specific functionality and operating elements
to a channel, in order to make it capable of a specific task.
The following channel roles can more or less freely be used :
Channel Role Description Additional Buttons Specific Input
Default for a simple input channel, no special behaviour
DJ for a mic source located in the control room (CR) Mute
Guest for a mic source located in the control room (CR) Talk
Input for sends 1 the bus owner of a N-1 bus Talk
Input for sends 2 the bus owner of a N-1 bus Talk
Input for sends 3 the bus owner of a N-1 bus Talk
Input for sends 4 the bus owner of a N-1 bus Talk
Track for the input channel that is linked to the Track Player Next, Display
Is linked to USB
In 3/4
Jingle for the input channel that is linked to the Jingle Player Jingle buttons
Is linked to USB
In 1/2
Already in the factory-reset state of the mixer, the channels have different
roles.
Channel
Number
Channel Role after Factory-Reset Channel Label Channel Source
1 DJ DJ MIC HQ MIC/LINE #1
2 Guest GUEST 1 HQ MIC/LINE #2
3 Guest GUEST 2 HQ MIC/LINE #3
4 Guest GUEST 3 HQ MIC/LINE #4
5 Input for sends 1 PHONE 1 ANALOG LINE #9
6 Input for sends 2 PHONE 2 ANALOG LINE #10
7 Jingle JINGLE USB 1/2
8 Track PLAYER USB 3/4
9 Default AES 1/2 AES 1/2
10 Default LINE 1/2 ANALOG LINE 5/6
11 Default LINE 3/4 ANALOG LINE 7/8
12 Default NET AES67/DANTE 1/2
Channel roles are configured in the Config View of a channel, under the
Source tab.
Depending on the channel role, the channel view can vary, because of addi-
tional buttons that need to be operatable.
