Micro Series
1-52 Micro Series
Document generated: 29.06.17
SW V1.1
The config page of the channels send section holds control elements necesarry
to set the channels send levels :
[1]
[4]
[2]
[3]
[1] Send levels These are the send levels of all input channels. Since the input channels are
fed “post-fader” to the send bus, these send levels can be regarded as a trim
function. Please note that the channel that we are currently configuring cannot
be sent to its own send bus (N-1 concept, also called mix-minus) .
[2] Master Send level Sets the output level of the send bus.
[3] On/Off Switches the output signal of the send bus on and off.
[4] Reset Resets all parameters.
2.3.2 Bus Config
Clicking/touching the Config button in the bus options view allows access
to the bus config page.
Two or three selection tabs navigate to the different sections. PRG and REC
busses have the tabs Targets and Outputs. All other busses have
Send, Targets and Outputs tabs.
