2.2.2 Bus options
Bus options are entered by doubleclicking or touching the send or bus label
when in send or bus view
[1]
[2]
[3]
[4]
[5]
[8]
[7]
[1] Bus assign Bus assign (for Sum and Aux busses) allows to assign all of the input chan-
nels to the currently viewed bus.
[2] Mono The Mono button mixes down the stereo signal to a mono signal and assigns
this signal to both, the Left and the Right leg of the stereo bus.
[3] Icon and Name Double-clicking on the name field allows the operator to enter a new bus
name. The icon is automatically chosen, depending on the bus type and bus
mode (Aux / N-1).
[4] USB Recorder Per default, the USB recorder is patched to the REC bus. If there is the need,
the USB recorder can be patched to any of the busses (Sum, N-1, Aux). There
is only one USB recorder available, which implies that it can only be patched
to one of the busses at the time.
[5] Config Config button. Pressing this button opens the configuration page of the current
bus. There, patching to outputs as well as chosing the bus mode and setting
the send levels can be done. Details see chapter 2.3.
