2.2.5 CR Monitoring options
By clicking/touching the CR Monitoring Options button, the CR monitor-
ing panel is shown :
[1]
[6]
[2]
[9]
[5]
[3] [4]
[7]
[8]
[1] CR monitoring source selector With these buttons the source for the control room monitoring is chosen. The
source is the same for the CR speakers and the CR headphones. The selected
source is displayed on the source displays
[2] Monitor Cut This button lets the operator manually cut the CR monitor.
[3] PFL to Mon With this option active, the current CR monitoring source gets replaced with
the PFL signal, as long as any PFL is active.
[4] Mono This button mixes the stereo CR source down to a mono signal for both, CR
speakers and CR headphones.
[5] Headphones Split Mode With this mode active, the PFL signal will be fed to the left channel of the
headphone, if PFL is active on any channel. On the right channel, still the pre-
viously selected CR source will be heard. Both signals are then downmixed
to mono.
Once PFL is released, the current CR source will be heard in stereo again.
If PFL is already selected as the CR source, actually pressing PFL on any
channel will not change the stereo PFL bus as the monitoring source.
[6] TB return level This rotary controls the incoming TB signal level which is fed to the CR
speakers as well as to the CR headphones. Please note that the current CR
source signal is then dimmed by 20dB.
