Studer Micro Series User Manual

Micro Series
1-88 Micro Series
Document generated: 29.06.17
SW V1.1
Off Air When a channel’s audio signal is not going to the PRG master - this channel
is Off Air.
On Air When a channel’s audio signal is being fed to the PRG master, this channel
is On Air.
On Master When a channel’s audio signal is either on PRG or REC master output
OVL Signal overload indication of a channel.
PFL PFL is pre-fader-listening.
PoE Power over Ethernet - a version of the physical layer of the Ethernet protocol
that carries a supply voltage which allows to power equipment directly from
the Ethernet cable (up to 25.5 W per unit)
PRG The program master bus
REC The record master bus
RTA Real Time Analyzer - a representation of the audio signal where level bars
over the frequency spectrum are calculated in real time.
TB Talkback.
WLAN Wireless Local Area Network - also called Wi-Fi.
