Micro Series
Micro Series 1-17
Document generated:29.06.17
SW V1.1
channels with analogue inputs, OVL is illuminated as soon as the input level,
before input calibration, reaches 0dBFS.
[3] SIG Indicator The green signal indicator is illuminated as soon as the signal is > -40dB. The
signal is captured after the INPUT processing block and therefore it is also
influenced by the analogue gain as well as the digital input calibration of the
channel.
[4] Fader The channel fader. It can be operated by mouse or touch. The mousewheel can
also be used to operate the fader when hovering the mousepointer anywhere
over the fader area.
[5] On button The On button activates the channel. When the fader is open, the On button
toggles the channel ‚on-air‘ and ‚off-air‘.
[6] PFL button The PFL button allows the operator to pre- listen to this channel even if the
fader is closed or the channel is not switched to ‚On‘. PFL stands for PreF-
adeListening. The Reset PFL button in the central section releases all channels
from PFL.
The channel of other roles than “Default” have additional buttons :
Role : DJ Guest Input for sends Track Jingle
[1] [2] [2] [3]
[4]
[5]
