Micro Series
Micro Series 1-35
Document generated:29.06.17
SW V1.1
[4] Pan On/Off The Pan On/Off button activates and deactivates the panning section.
[5] Bus assign buttons These buttons assign the input channel to the desired busses.
[6] Config button Pressing this button opens the configuration page of the current channel.
There, the detailed channel configuration can be carried out, such as EQ
parameter setting, Dynamics parameter setting, etc..Details see chapter 2.3.
[7] Back to operation view Clicking or touching onto the area in the top right corner navigates back to
the operation view.
[8] Navigation Navigation to the option pages of other channels is provided on the bottom
channel navigation bar.
On channels of the role “Input for send”, there is an additional control element
:
[1]
[1] Send signal and Send level For “Input for send”- channels, on the channel options page also the bus for
the send signal, as well as its level can be chosen. “Input for send” - channels
are in other terms the N-1 bus owner channel. The send signal can then be
called the N-1 mix or the mix-minus signal.
The send level can also be set on the channel send view.
