Micro Series
Micro Series 1-43
Document generated:29.06.17
SW V1.1
Jingle
Track
Depending on the channel role, the channels control elements on the GUI are
different.
[4] Test tone With these two buttons. test tone can be fed to the left and the right leg of the
channel. The test tone signal is defined in the “Settings”-page
[5] Navigation back. Clicking or touching onto this area navigates back to the Options page of this
channel.
[6] Back to operation view Clicking or touching onto the area in the top right corner navigates back to
the operation view.
[7] Navigation to other channels Navigation to the config pages of other channels is provided on the bottom
channel navigation bar.
