On the Clock Sync tab, the sampling rate as well as the sync options can be
found.
[1]
[2]
[3]
[1] Sampling Rate Sets the sampling rate to either 44.1kHz or 48 kHz.
[2] Preferred Sync Source selection The mixer’s preferred sync source can be chosen here. As the standard, the
internal sync generator is used. If desired, the mixer can be synchronised to
the clock received on either the Wordclock-, or one of the AES inputs. The
Source State indicators then show the state of each possible sync source.
The sync logic makes sure that the preferred sync source becomes active if
there is a valid signal with the desired sampling rate. If the preferred sync
source is not valid, the sync logic switches to the internal sync generator.
[3] Sync State This is the display of the current sync source.
If e.g. the selected sampling rate is 48kHz and word clock is the selected
Sync Source, but the external word clock provides 44.1kHz or is even not
available, the Sync State will indicate INTERNAL, as the sync logic defaults
to internal clock generator running on the selected sampling rate.
