SummaCut cutter User’s Manual
Basic Operation 2-5
4. Press or to change the knife offset.
The value will change
1. Press
to perform the internal knife offset test.
2. Press
to confirm the chosen knife offset.
3. Press
to leave the offset unchanged.
When the knife offset is set correctly, the test pattern looks like this:
FIG 2-2
2-2 CORRECT KNIFE OFFSET PATTERN
When the knife offset is too low, the test pattern looks like this:
When the knife offset is too high, the test pattern looks like this:
