SummaCut cutter User’s Manual
Contour Cutting 3-16
NOTE: The second and any following sheets must be loaded in the cutter at the same
position as and with the same orientation of the first sheet. When in OPOS sheet mode,
the cutter stores the distance between edges of the sheet and the first OPOS marker.
TIP: Use easy orientation points to be able to quickly position the sheet. In the figure
below, a rim of the base plate and the side of the pinch roller assembly are used to align
the sheets.
FIG 3-1
3-1 POSITION MEDIA FRO MULTIPLE SHEET
