SummaSign Pro T-series Cutters User’s Manual
Contour Cutting 5.9
♦ Fill in the values for the marker distances and press OK:
5.7 REGISTRATING THE CROSS-MARKS
• Before proceeding, make sure all the cutting parameters are correct
(pressure, velocity, …). See User’s Manual.
• Press the key until the message 'SPECIAL LOAD' is displayed on the
LCD.
SPECIAL LOAD
↵
• Press the key.
DIGITIZE ORIGIN
X = 0 Y = 0 ↵
• Position the knife tip exactly above the origin-marker using the ,
,
, jogging keys.
During this entire procedure, make sure that the knife does not rotate, which
may cause an offset error.
Indicate the cross-marks with extreme accuracy because it directly
influences the result.
