SINGLE PHASE HI 10/12kW | User Manual10
TECHNICAL SPECIFICATIONS
Model SUNSYNK-10K-SG02LP1 SUNSYNK-12K-SG02LP1
Battery Input Data
Battery Type Lead-acid or Lithium-ion
Battery Voltage Range 40~60V
Max. Charge Current 220A 250A
Max. Discharge Current 220A 250A
Charging Curve 3 Stages/Equalisation
External Temperature Sensor Yes
Charging Strategy for Li-Ion Battery Self-Adaptation to BMS
PV String Input Data
Max. DC Input Power 13000W 15600W
Max PV Input Voltage 370V (125~500V)
MPPT Range 150V~425V
Full Load DC Voltage Range 200~425
Start-up Voltage 125V
PV Input Current 26A+26A+26A
Max. PV Isc 44A+44A+44A
No. of MPPT / Strings Per MPPT 3 / 2+2+2
AC Output Data
Max. On-Grid AC Power 10000 12000
Max. O-Grid AC Power 11000 13200
Peak Power (o-grid) 2 times of rated power, 10 S
AC Output Rated Current 45.5/43.5A 54.6/52.2A
Max AC Current 50/47.9A 60/57.4A
Max Continuous AC Passthrough 60A
Power Factor 0.8 leading to 0.8 lagging
Output Frequency and Voltage 50Hz/60Hz; 220/230Vac
Grid Type Single-Phase
Current Harmonic Distortion THD < 3% (of nominal power)
DC Current Injection <0.5% In
Eciency
Max. Eciency 97.60%
Euro Eciency 96.50%
MPPT Eciency >99%
Protection
Integrated
PV Arc Fault Detection, PV Input Lightning Protection, Anti-islanding
Protection, PV String Input Reverse Polarity Protection, Insulation
Resistor Detection, Residual Current Monitoring Unit, Output Over
Current Protection, Output Shorted Protection, Surge Protection,
Over Voltage Category.
Certications and Standards
Grid Regulation
IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140,
UNE 217002, OVE-Richtlinie R25, G99, G98, VDE-AR-N 4105
Safety EMC / Standard IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
