SINGLE PHASE HI 10/12kW | User Manual30
Three-Phase Parallel Inverter
L wireCAN N wire PE wire
Battery Pack
Grid
L1 L2 L3 N PE
A Phase Inverter No.1(master) B Phase Inverter No.2(master) C Phase Inverter No.3(master)
L3 L2 L1 N PE
Parallel A Parallel B
A Phase Master inverter B Phase Master inverter C Phase Master inverter
CAN/RS 485
Backup Load
E-BAR
N-BAR
Home load
CT
CT3
CT2
CT1
Arrow pointing
to
inverter
6. AC Breaker
5. AC Breaker
4. AC Breaker
1. DC Breaker
2. DC Breaker
3. DC Breaker
Ground
1/2/3. DC Breaker for battery
SUNSYNK-10K-SG02LP1: 300A DC breaker SUNSYNK-12K-SG02LP1: 300A DC breaker
5. AC Breaker for grid port
SUNSYNK-10K-SG02LP1: 100A AC breaker SUNSYNK-12K-SG02LP1: 100A AC breaker
4. AC Breaker for backup load port
SUNSYNK-10K-SG02LP1: 100A AC breaker SUNSYNK-12K-SG02LP1: 100A AC breaker
6. AC Breaker Depends on Home Load
01 02 03
