SWE90UF-2PB Operation & Maintenance Manual
hydraulic oil on the ring section. Push filter core
upward while moving it forward and backward
alternately to install it.
Clean filter housing.
Rotate clockwise to tighten filter housing to head
cover. Tighten at torque: 19.5—29.5Nm (2-3 kgf.m).
(8) Engine Hood Label
Warning
Shut down engine before opening engine hood.
Be cautious of scalding after opening engine hood.
(9) Work Device Label
Warning
Stay clear of working device.
(10) Swing Label
Warning
Keep clear of swing area.
(11) Tail Warning Label
Warning
Stay clear of machine while it is running.
(12) Lifting Direction Label
