SUNWARD SWE90UF-2PB - Cab（Closed

SWE90UF-2PB Operation & Maintenance Manual
52
3.2 CAB（CLOSED）
1．Throttle knob
2
．
Air conditioner panel
3
．
Seat
4．Pilot handle
5．Left operating handle
6．Deflection control pedal
7. Left travel control lever
8．Right travel control lever
9
．
Boom section two control pedal
10
．
Display screen
11
．
Right operating handle
12．Dozer blade control handle
13．Rocker control switch
14．Engine ignition lock
15. Radio control panel
