SWE90UF-2PB Operation & Maintenance Manual
57
5 —Regeneration request switch
This switch should be turned on when the regeneration should be done manually. Details, please refer to
the operational technological instruction of YAMAR regeneration rocker switch.
6 —Regeneration interlock switch
This switch should be turned on when the regeneration should be done manually. Details, please refer to
the operational technological instruction of YAMAR regeneration rocker switch.
7 — Quick-change lock switch
When pressing down the switch, the bucket is controlled to assemble and disassemble automatically.
8 —Warning light switch
This switch controls the warning light. After pressing down the switch, the warning light starts flicker and the
icon will be on for red. Then press it again, the red icon will extinguish and the warning light will stop flicker.
9 — Key switch (As figure 3.4.2)
① —OFF
（
engine stop
）
② —ON
（
power on
）
③ —HEAT (preheating)
④ — START
（
engine start
）
10 — Cigar lighter (As figure 3.4.3)
Press this device, it will rebound after a few seconds, take it out and kindle cigarette.
FIG. 3.4.2
9
1
2
3
4
FIG. 3.4.3
10
