1-6
X10SLV/-Q Motherboard User's Manual
Motherboard Features
CPU Supports a single, 4th generation Intel® Core™ i7/i5/i3
processor (LGA1150)
Memory Two (2) SO-DIMM slots support up to 16 GB of DDR3,
1600/1333/1066 MHz, unbuffered, non-ECC SO-DIMM
memory
Supports One DIMM per Channel
DIMM sizes
SO-DIMM 2 GB, 4 GB and 8GB
Chipset X10SLV: Intel® H81 Express
X10SLV-Q: Intel® Q87 Express
Expansion Slots One (1) PCI-E x 16, Gen2 (Gen3 for X10SLV-Q only)
Graphics Intel Integrated Graphics
Independent Displays X10SLV: Two
X10SLV-Q: Three
Network Connections Two (2) RJ-45 Rear I/O Panel Connectors (Intel I217V +
I210AT)
I/O Devices SATA Connections
X10SLV Only
SATA 3.0 Ports Two (2)
SATA 2.0 Ports Two (2)
mSATA 3.0 Ports One (1) - Share with SATA3*
X10SLV-Q
SATA 3.0 Ports Four (4), RAID 0,1,5,10
mSATA 3.0 Ports One (1) - Share with SATA3*
*The mSATA port is shared with the SATA3 ports. Either the SATA3 ports are
used or the mSATA port, but not at the same time.
USB Devices
Two (2) USB 3.0 ports on the rear I/O panel
Six (6) USB 2.0 ports (2 on rear I/O panel, 2 via on board
headers, One (1) type A
Graphics
One (1) DisplayPort, One (1) DVI-I port, One (1) HDMI
Keyboard/Mouse
Keyboard/Mouse support via USB ports
Serial (COM) Ports
Five (5) COM ports (1 x RS232/422/485, 4 x RS232)
