Chapter 2: Installation
2-19
LAN1
LAN2
1
LAN Ports (LAN1/LAN2)
T
wo gigabit
LAN ports are
located on
the
I/O
back panel.
These
ports
accept RJ45
type cables and are used to connect the
motherboard
to
a
network.
1
2
2
Back Panel Connectors
RJ45/LAN
Pin Denitions
Pin # Denition
Pin # Denition
1
TX_D1+
5
BI_D3-
2
TX_D1-
6
RX_D2-
3
RX_D2+
7
BI_D4+
4
BI_D3+
8
BI_D4-
1
2
42
44
