Chapter 2: Installation
2-15
I/O
Port
Locations
and
Denitions
2-6
Connectors/I/O Ports
The I/O ports are color coded in conformance with the PC 99
specication. See the
gure
below
for
the
colors
and
locations
of
the
various
I/O
ports.
Back Panel Connectors and I/O Ports
2
4
7
1
3
5
6
8
1. DisplayPort
8. USB2 (2.0)
2. HDMI Port
9. DVI-I Port
3. Gb LAN1 Port
10. COM2
4. USB1 (3.0)
1
1. COM1
5. USB0 (3.0)
12.
Audio Line In*
6. Gb LAN2 Port
13.
Audio Line Out*
7. USB3 (2.0)
14.
Audio Mic In*
Back Panel Connectors
6
11
10
12
13
14
*X10SL
V
only
38
40
