LED Definitions
In addition to beeper sequences, the digital scanner uses a two-color LED to indicate its status, and the cradle’s
LED indicates charge and communication status. Table explains digital scanner LED sequences, and Table
explains cradle LED sequences.
Table 2-2 Scanner LED Status Indications
LED Indication
Standard Use
Off No power is applied to the digital scanner (battery is discharged or
removed); digital scanner is in low power and ready to scan.
Green A bar code was successfully decoded.
Red A data transmission error, digital scanner malfunction, or the DS3578 digital
scanner was inserted into an STB3478 cradle.
Charging Use
Green Slow Flash The digital scanner charges at the slow rate (used when a host cable
powers the cradle).
Green Fast Flash The digital scanner charges at the fast rate (used when an external power
supply powers the cradle).
Red flash Charging problem. Contact
Motorola Solutions Support .
The DS3578 digital scanner was inserted into an STB3478 cradle.
Red and green flash Temperature fault. Move the cradle to a location where the temperature is
0
o
- 40
o
C; optimal charging temperature is 5
o
- 35
o
C.
Table 2-3 Cradle LED Status Indications
LED Indication
Blue Cradle is powered.
Red Transmission error, or you inserted an DS3478 digital scanner into the
STB3578 cradle.
